Introduction

Recently, circularly polarized (CP) omnidirectional antennas are of great interest since they can effectively reduce multipath effects, enhance the stability of wireless communication systems and provide a wide signal coverage. Therefore, a large number of efforts have been put into developing CP omnidirectional antennas [1–8]. In Ref. 1, by introducing shorting vias and vortex slots into a monopolar patch antenna, omnidirectional radiation patterns and wide axial ratio (AR) bandwidth were achieved. Based on dielectric resonator antennas, the designs presented in Refs. 2 and 3 could achieve AR bandwidths of 25.4 and 54.9%, respectively. However, the aforementioned designs all had profiles of more than 0.1λ0, which are not appropriate for space-limited applications. Patch antennas have advantages of low profile and simple structures, and are therefore suitable for designing CP omnidirectional antennas [4–8]. For instance, in Refs. 4–6, the antennas loaded with curved branches owned profiles of lower than 0.07λ0 and AR bandwidths of more than 14%. In Refs. 7 and 8, by cutting slits on radiating patches and ground planes, CP omnidirectional radiation performances were obtained and the antenna heights were only 0.028 and 0.026λ0, respectively.

With the blooming of wireless technologies, antennas with more than one operating band are becoming more and more necessary to satisfy various wireless standards. In Ref. 9, a dual-band CP omnidirectional antenna was proposed. By combining a dielectric resonator antenna and a patch antenna together, the design was able to realize AR bandwidths of 3.16 and 5.06% at two bands, separately. In Ref. 10, by utilizing a stacked-patch configuration, a dual-band frequency reconfigurable antenna was presented. In addition, based on artificial μ-negative transmission lines, a dual-band CP antenna was investigated in Ref. 11. As it is known, CP antennas are required for global positioning systems, satellite communications and linearly polarized antennas are needed for lots of other commercial applications. But few published designs are able to offer dual-band omnidirectional antennas with different polarization states in the two frequency bands. In Ref. 12, a dual-band dual-polarized antenna was proposed. Omnidirectional circular polarization is achieved in the low band and omnidirectional linear polarization is obtained in the high band. In Ref. 13, a dual-band antenna with different polarization and radiation properties over two bands for vehicular communications is presented. However, the AR bandwidth of the designs [12, 13] is too narrow to satisfy the modern wireless systems.

In this paper, a dual-band dual-polarized omnidirectional antenna is presented. The two bands are generated by two circular patches, separately. By adding a set of conductive vias and a coupled ring, the antenna bandwidths are enhanced significantly [14, 15]. Owing to the introduction of curved branches, a current loop can be formed to provide horizontally polarized field. Together with the vertically polarized field created by the lower circular patch, a CP omnidirectional radiation can be generated in the low band. To verify the design idea, a prototype was designed, fabricated and measured. Both simulated and measured results reveal that wide bandwidths, omnidirectional circular polarization and omnidirectional linear polarization can be achieved.

Antenna Geometry and Operating Principle

Antenna Geometry

Figure 1 shows the geometry of the proposed dual-band dual-polarized omnidirectional antenna and the detailed dimensions are listed in Table 1. As shown in Figure 1, the proposed antenna is mainly composed of an upper circular patch, an annular ring, a lower circular patch, a set of conductive vias, a ground plane, six curved branches and a coaxial probe. The upper circular patch is printed on the top of Substrate 1 (Taconic RF-30, thickness = 1 mm, εr = 3.0) and the annular ring is concentrically placed around the upper circular patch. The lower circular patch and the ground plane are printed on the top and bottom surfaces of Substrate 2 (Rogers 5,870, thickness = 3.175 mm, εr = 2.33). In order to excite two circular patches simultaneously to achieve a dual-band property, a clearance hole with a radius of 2.5 mm is etched in the center of the lower circular patch. In this way, the upper circular patch is directly fed by the inner conductor of the coaxial probe and the lower circular patch is fed by the coupling with the clearance hole. As a result, the design is able to operate at two bands. In addition, a set of N conductive vias (N = 15) are used to short the lower circular patch to the ground plane and six curved branches are loaded around the ground plane to contribute CP radiation in the low band.

FIGURE 1

FIGURE 1. Geometry of the proposed dual-band dual-polarized omnidirectional antenna: (A) Top view of Substrate 1; (B) Top view of Substrate 2; (C) Bottom view of Substrate 2; (D) Side view.

TABLE 1

Operating Principle

As previously stated, by adding the annular ring and a set of conductive vias into the antenna structure, antenna bandwidths can be enhanced dramatically. The curved branches are used to contribute CP radiation. Therefore, in this part, principles of the annular ring, the conductive vias and the curved branches will be further discussed.

Polarized

In this design, the annular ring is concentrically placed around the upper circular patch. In consequence, when the upper circular patch is fed, the annular ring can be excited simultaneously by energy coupling. By tuning the radius of the upper circular patch, the size of the annular ring and the distance between them, their resonant frequencies can be moved in proximity to each other. Hence, a wide impedance bandwidth can be obtained in the high band.

As illustrated in Ref. 15, a non-zero resonant frequency of TM01 mode can be created due to the loading of conductive vias. Together with the well-known TM02 mode generated by the lower circular patch, a wide impedance bandwidth can be realized then. The number, radius, and location of the conductive vias have effect on impedance matching of the antenna, and these parameters can be determined based on the design guideline given in Ref. 15.

As it is known, CP radiation requires two orthogonal electric fields with an equal amplitude and 90° phase difference. In this design, TMmn mode (m = 0, n = 1, 2) is generated by the vias-loaded lower circular patch, leading to vertically polarized electric field Eθ. And the introduction of curved branches can form a current loop around the ground plane, leading to horizontally polarized electric field Eφ. When these two orthogonal fields have an equal amplitude and a quadrature phase difference, CP radiation is achieved in the far field. Figure 2 gives the simulated current distribution on the lower circular patch and the ground plane at 2.4 GHz. It is seen that an equivalent vertical current formed by the circular patch and a current loop formed by the curved branch on the ground plane are excited simultaneously. Hence, circular polarization is achieved.

FIGURE 2. Simulated current distribution on the lower circular patch and ground plane.

Results

To verify the proposed design, a fully functional prototype shown in Figure 3 was fabricated and measured. Ansys HFSS, a vector network analyzer and a near-field measurement system were used to obtain the simulated and measured results.

FIGURE 3

Simulated and measured S-parameters and axial ratios (ARs) of the proposed antenna are given in Figure 4. From the figure, it can be seen that the measured impedance bandwidths for S11 ≤ −10 dB are from 2.2 to 2.62 GHz in the low band and from 5.63 to 6.29 GHz in the high band, which agree well with the simulated results. The measured AR bandwidth for AR ≤ 3 dB is from 2.22 to 2.58 GHz. Therefore, the effective bandwidths of the proposed design are from 2.22 to 2.58 GHz and 5.63–6.29 GHz at two bands, respectively. Figure 5 shows the simulated and measured peak gains of the proposed antenna. The measured peak gains are approximately 4.3 dBic in the low band and 5.4 dBi in the high band. The discrepancies between the simulated and measured gains are mainly due to the fabrication tolerances and imperfect measurement system.

FIGURE 4. Simulated and measured S-parameters and ARs: (A) low band; (B) high band.

FIGURE 5

FIGURE 5. Simulated and measured antenna gains: (A) low band; (B) high band.

The simulated and measured radiation patterns in the azimuth plane (θ = 30°) and elevation plane (φ = 0°) at 2.35, 2.55 and 5.9 GHz are depicted in Figure 6. The measured radiation patterns are in well agreement with simulations. In the low band, omnidirectional radiation patterns can be observed and the left-hand (LH) CP fields are almost 15 dB stronger than the right-hand (RH) CP fields at θ = 30° and the whole azimuth plane, demonstrating LHCP radiation is achieved in the far field of the proposed design. In the high band, omnidirectional radiation patterns are also obtained and the cross-polarization levels are lower than −15 dB compared with the co-polarization counterpart in both planes. In consequence, a dual-band and dual-polarized antenna with well-controlled omnidirectional radiation patterns is realized in this design.

FIGURE 6
SlotSlot

FIGURE 6. Simulated and measured radiation patterns: (A) 2.35 GHz; (B) 2.55 GHz; (C) 5.9 GHz.

Conclusion

A Dual-polarization Slot Antenna Using A Compact Cpw Feeding Structure

In this paper, a low-profile dual-band dual-polarized omnidirectional antenna has been proposed. A prototype was constructed and measured to demonstrate the antenna performance. The proposed antenna can achieve bandwidths of 15 and 11.1%, gains of approximately 4.3 dBic and 5.4 dBi at two bands, respectively. Besides, omnidirectional radiations with low cross-polarization levels can also be obtained. With these properties, the proposed antenna shows superiorities over the reported designs and is attractive for indoor communication systems.

Data Availability Statement

The original contributions presented in the study are included in the article/Supplementary Material, further inquiries can be directed to the corresponding author.

Author Contributions

All authors listed have made a substantial, direct, and intellectual contribution to the work and approved it for publication.

Funding

This work was supported by the Key Research and Development Project of Guangdong Province (2020B0101080001) and the National Natural Science Foundation of China (62071308). (Corresponding author: LG).

Conflict of Interest

The authors declare that the research was conducted in the absence of any commercial or financial relationships that could be construed as a potential conflict of interest.

References

1. Yu D, Gong SX, Wan YT, Yao YL, Xu YX, Wang FW. Wideband omnidirectional circularly polarized patch antenna based on vortex slots and shorting vias. IEEE Trans Antennas Propag (2014) 62(8):3970–7. doi:10.1109/tap.2014.2325961

CrossRef Full Text Google Scholar

2. Pan YM., Leung KW. Wideband circularly polarized dielectric bird-net antenna with conical radiation pattern. IEEE Trans Antennas Propag (2013) 61(2):563–70. doi:10.1109/TAP.2012.2220101

CrossRef Full Text Google Scholar

3. Pan YM, Leung KW. Wideband omnidirectional circularly polarized dielectric resonator antenna with parasitic strips. IEEE Trans Antennas Propag (2012) 60(6):2992–2997. doi:10.1109/TAP.2012.2194678

CrossRef Full Text Google Scholar

4. Lin W, Wong H. Circularly polarized conical-beam antenna with wide bandwidth and low profile. IEEE Trans. Antennas Propag. (2014) 62(12):5974–5982. doi:10.1109/tap.2014.2360223

CrossRef Full Text Google Scholar

5. Lin W, Wong H. Polarization reconfigurable wheel-shaped antenna with conical-beam radiation pattern. IEEE Trans Antennas Propag (2015) 63(2):491–499. doi:10.1109/tap.2014.2381263

CrossRef Full Text Google Scholar

6. Chen X, Zhang WM, Han LP, Chen XW, Ma RB, Han GR. Wideband circularly polarized antenna realizing omnidirectional radiation in the wider azimuth planes. IEEE Antennas Wireless Propag Lett (2017) 16(8):2461–2464. doi:10.1109/lawp.2017.2724082

Dual-polarized Slot-coupled Planar Antenna With Wide Bandwidth

CrossRef Full Text Google Scholar

7. Guo CF, Yang RC, Zhang WM. Compact omnidirectional circularly polarized antenna loaded with complementary V-shaped slits. IEEE Antennas Wireless Propag Lett (2018) 17(9):1593–1597. doi:10.1109/lawp.2018.2856504

CrossRef Full Text Google Scholar

8. Shi YZ, Liu JH. Wideband and low-profile omnidirectional circularly polarized antenna with slits and shorting-vias. IEEE Antennas Wireless Propag Lett (2016) 15(3):686–689. doi:10.1109/lawp.2015.2469277

CrossRef Full Text Google Scholar

9. Pan YM, Zheng SY, Li WW. Dual-band and dual-sense omnidirectional circularly polarized antenna. IEEE Antennas Wireless Propag Lett (2014) 13(4):706–709. doi:10.1109/lawp.2014.2314744

CrossRef Full Text Google Scholar

10. Ge L, Li M, Wang J, Gu H. Unidirectional dual-band stacked patch antenna with independent frequency reconfiguration. IEEE Antennas Wireless Propag Lett (2017) 16(2):113–116. doi:10.1109/lawp.2016.2558658

CrossRef Full Text Google Scholar

11. Chen X, Han LP, Chen XW, Zhang WM. Dual-Band Circularly Polarized Antenna Using Mu-Negative Transmission Lines. IEEE Antennas Wireless Propag Lett (2018) 17(7):1190–1194. doi:10.1109/lawp.2018.2838145

CrossRef Full Text Google Scholar

12. Liu Y, Li X, Yang L, Liu Y. A dual-polarized dual-band antenna with omnidirectional radiation patterns. IEEE Trans Antennas Propag (2017) 65(8):4259–4262. doi:10.1109/tap.2017.2708093

Dual-polarization Slot-coupled Printed Antennas Fed By Stripline

CrossRef Full Text Google Scholar

13. Ge L, Gao S, Li Y, Qin W, Wang J. A low-profile dual-band antenna with different polarization and radiation properties over two bands for vehicular communications. IEEE Trans Veh Technol (2019) 68(1):1004–1008. doi:10.1109/tvt.2018.2881765

CrossRef Full Text Google Scholar

14. Zhang YY, Liu JH, Liang ZX, Long YL. A wide-bandwidth monopolar patch antenna with dual-ring couplers. Int J Antennas Propag. (2014) 13(4):710–713. doi:10.1155/2014/980120

Design Of Wideband Dual Polarized Slot Antenna

CrossRef Full Text Google Scholar

15. Liu JH, Xue Q, Wong H, Lai HW, Long YL. Design and analysis of a low-profile and broadband microstrip monopolar patch antenna. IEEE Trans Antennas Propag (2013) 61(1):11–18. doi:10.1109/tap.2012.2214996

Broadband Dual Circularly Polarized Square Slot Antenna

CrossRef Full Text Google Scholar
